42% off
Light- Filtering Roller Shades
$35.00 USD
$60.00
Unit price
/
Unavailable
Shipping calculated at checkout.
Measurement & Installation
Measuring is easy - Let us show you how!
Here are some quick tips and notes to remember:
- Use a steel measuring tape
- Round down to the nearest 1/8" for width
- Round up to the nearest 1/8" for height
- Always reference product specifications for complete measuring instructions
Specifications and Installation
Depth and Space Requirements
| Mounting Type | Inside Mini Depth | Inside Mount Flush Depth | Outside Mount Minimum Space |
|---|---|---|---|
| Cordless Lift | 2 1/2" | 3" | 2" |
| Exposed Roll | 2 1/4" | 3" | 2" (All Other Features) |
| Fabric Insert Cassette | 2 5/8" | 3 1/4" (Cassette) | 2" (All Other Features) |
| Aluminum Cassette | 3 1/4" | 3 3/4" (Large Cassette) | 2" (All Other Features) |
Width and Height Ranges
| Lift Type | Width Range | Height Range |
|---|---|---|
| Cordless Lift | 14" - 95" | 12" - 105" |
| Continuous Cord Loop | 14" - 103" | 12" - 120" |
| Motorized Lift | 20" - 96" | 18" - 120" |
Fabric Deductions
| Mounting Type | Cordless Lift | Continuous Cord Loop | Motorized Lift |
|---|---|---|---|
| Exposed Roll | 35mm = 1 3/8" total deductions | 37mm = 1 1/8" total deductions | 35mm = 1 3/8" total deductions |
| Cassette Type A | 22mm = 7/8" total deductions | 26mm = 1 1/8" total deductions | 23mm = 7/8" total deductions |
| Cassette Type D | 25mm = 1" total deductions | 31mm = 1 1/4" total deductions | 28mm = 1 1/16" total deductions |
Light Gap - Open Roll
| Side | Cordless Lift | Continuous Cord Loop | Motorized Lift |
|---|---|---|---|
| Chain Side | 18mm = 11/16" total deductions | 20mm = 6/8" total deductions | 18mm = 11/16" total deductions |
| Opposite Side | 17mm = 11/16" total deductions | 17mm = 11/16" total deductions | 17mm = 11/16" total deductions |
Light Gap - Type A Cassette
| Side | Cordless Lift | Continuous Cord Loop | Motorized Lift |
|---|---|---|---|
| Chain Side | 17mm = 11/16" total deductions | 21mm = 6/8" total deductions | 18mm = 11/16" total deductions |
| Opposite Side | 5mm = 5/16" total deductions | 5mm = 5/16" total deductions | 5mm = 5/16" total deductions |
Light Gap - Type D Cassette
| Side | Cordless Lift | Continuous Cord Loop | Motorized Lift |
|---|---|---|---|
| Chain Side | 15mm = 9/16" total deductions | 21mm = 6/8" total deductions | 18mm = 11/16" total deductions |
| Opposite Side | 10mm = 3/8" total deductions | 10mm = 3/8" total deductions | 10mm = 3/8" total deductions |
Chain Guard Lengths
| Length of Shade | Length of Chain Guard |
|---|---|
| ≤ 36" | 13 1/4" |
| 36 1/16" - 54" | 25 1/4" |
| 54 1/16" - 72" | 37 1/4" |
| 72 1/16" - 90" | 49 1/4" |
| 90" | 61 1/4" |
Recommendations and Limitations
Important Notes
- There may be a +/- 1/8 inch measurement discrepancy. When measuring curtain dimensions, do not account for factory deductions. Detailed deduction information can be found in the table below.
- For outside-mounted curtains with exposed rollers, the mounting brackets will always be visible regardless of the roller type chosen.
- In order to ensure uniform fabric alignment, it is critical that you indicate on your order whether shades are to be installed side-by-side or in the same room.
- Fabric colour can vary from one dye lot to another. To ensure that all materials are from the same dye lot, please order shades for the same room at the same time.
Additional Information
- The back of full blackout products is white.
- According to legal requirements, safety devices must be installed on chains to prevent the formation of hanging loops. The safety device should be installed at the farthest point from the control mechanism to prevent slack in the cord loop.
- Continuous cord loops come with white chains.
- Fabric-inserted cassette tracks use the same fabric as the curtain, with the fabric direction consistent with the curtain. The matching bottom rail is white.
- Exposed roller brackets and covers will be black or white depending on the fabric chosen.
- Aluminum cassettes are available in five colors, with the bottom rail matching the cassette color.
Motorization Details
- Motorized remotes are not included. At least one remote is required per order, and one motorized charger is included in each order.
- It is strongly recommended to set up a dedicated channel for each curtain.
- A 15-channel remote can operate one curtain per channel, controlling up to 15 curtains in total.
- The remote range is approximately 260 feet.
- An additional Hub allows control of motorized curtains via Alexa and the free, downloadable Tuya Smart app, compatible with iOS and Android systems.
Shipping & Return
- Enjoy free shipping on all orders within the contiguous United States.
- Each is custom-made to your exact specifications and generally ships within 3 to 5 business days after your order is placed.
- We hold all orders for 24 hours before processing to allow time for any adjustments to measurements or color choices.
- Please note that shipping may take an additional 3 to 7 business days.
- For customized shades, and blinds, we usually will not accept returns. Click to see more return policy
How They'll Help You
Our Light Filtering Roller Shades beautifully balance privacy and natural light, creating a gentle, illuminated ambiance in any room. This collection offers a versatile range of fabric options, each designed to enhance your décor with unique textures and modern styles:
For a polished finish, you can customize the roll style with a matching cassette headrail, fabric insert, and a white bottom rail to completely conceal the roller. You can also choose an aluminum valance, available in 5 colors with a matching color bottom rail.
Each shade comes standard with a classic continuous cord loop for easy operation. Prefer a cleaner, safer option? Upgrade to a free, kid-friendly cordless lift system to keep your walls and windows looking streamlined and tidy.
Light- Filtering Roller Shades
Why Add Motorization?
- Smart home integration
- Voice, app, or remote activated
- Automated scheduling
Get FREE Fabric Swatches!
Explore the perfect window treatments for your space with our Sample.
- ULURU 11: Featuring bold linear or wave-like patterns, this series delivers a dynamic and textured look, perfect for adding visual impact and character to your space.
- Arizona 11: Subtle crosshatch or horizontal patterns define this series, providing a refined and balanced aesthetic for understated elegance.
- Shantung 11: Smooth fabrics with faint linear patterns offer a delicate, subtle texture, blending seamlessly into minimalist and modern interiors.
- Solid AYM Series: A selection of timeless, on-trend solid colors with a sleek and clean finish, perfect for creating a modern, streamlined look that pairs effortlessly with any interior style.
